    5Kwh 10Kwh All In One ESS Solution 15Kwh 20Kwh 25Kwh Lithium Ion Battery For Inverter

    Ask Lasest Price
    Brand Name : Redway
    Model Number : PW48105-I
    Certification : CE RoHS MSDS
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10000PCS/Day
    Delivery Time : 20Days
    • Product Details
    • Company Profile

    5Kwh 10Kwh All In One ESS Solution 15Kwh 20Kwh 25Kwh Lithium Ion Battery For Inverter

    Product Description

    all in one 5Kwh 10Kwh 15Kwh 20Kwh 25Kwh lithium battery with inverter

    Stackable lithium batteries offer the flexibility to expand capacity and voltage, high energy density, reliable performance, and long cycle life. They are widely used in a diverse range of industries and applications that require scalable and efficient energy storage solutions.


    These batteries are used in various applications, including renewable energy storage systems, electric vehicles, telecommunications, uninterruptible power supplies (UPS), backup power solutions, and more. Their compact design, lightweight nature, and versatile performance make them a popular choice for applications where space, portability, and scalability are important considerations.


    Characteristics of stackable batteries


    Long Cycle Life: The batteries exhibit a long cycle life, enabling them to endure frequent charge and discharge cycles without significant capacity degradation.


    Fast Charging Capability: Stackable batteries often feature fast charging capabilities, minimizing downtime and allowing for quick recharge to full capacity.


    Compact Design: Despite their high energy storage capacity, stackable batteries are designed to be compact and space-efficient, making them suitable for applications with limited space.


    Lightweight: The batteries are relatively lightweight, offering advantages in terms of portability and ease of handling during installation and maintenance.


    Low Self-Discharge Rate: Stackable batteries have a low self-discharge rate, ensuring they retain their charge for extended periods when not in use.


    ItemsSpecification
    Battery
    Number of Batteries123456
    Battery Energy5.04kWh10.08kWh15.12kWh20.16kWh25.2kWh30.24kWh
    Battery Capacity105Ah210Ah315Ah420Ah525Ah630Ah
    Weight (Inverter+Battery+Base)64.5kg (142.19 lbs)108.8kg (239.86 lbs)153.1kg (337.52 lbs)197.4kg (435.19 lbs)241.7kg (532.85 lbs)285.9kg (630.3 lbs)
    Dimension [L*D*H]580*420*430 mm (22.83*16.53*16.92 inch)580*420*615 mm (22.83*16.53*24.21 inch)580*420*800 mm (22.83*16.53*31.49 inch)580*420*985 mm (22.83*16.53*38.77 inch)580*420*1170 mm (22.83*16.53*46.06 inch)580*420*1355 mm (22.83*16.53*53.34 inch)
    Cell TypeLiFePO4
    (Customizable: LiFePO4 / NCM / Prismatic / Cylindrical)
    Battery Voltage48V
    Working Voltage37.5V~54.75V
    Maximum Charge Current100A Continuous
    Maximum Discharge Current100A Continuous
    Fast ChargingSupports Fast Charging
    Charging Temperature0~50°C (32℉~122℉)
    Discharging Temperature-15~55°C (5℉~131℉)
    Operating Humidity Range<80%
    Nominal Operation Altitude<4000m
    Max. Parallel Connection6
    Cycle Life (25°C / 77℉@60% DOD)>8000 Cycles
    Cycle Life (25°C / 77℉@80% DOD)>6000 Cycles
    Cooling ModeForce Air Cooling
    Noise60 dB
    Operation EnvironmentIndoor
    Installation MethodHorizontal
    Self-Discharge Rate<3% per month (25°C / 77℉)
    IP GradeIP20 (Higher grade optional)
    Battery CaseSteel
    Monitoring & ProtectionSmart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit
    CommunicationRS485
    Optional FunctionsBluetooth / WiFi / CAN / Circuit Breaker / Heating / Active Balance / LED Touch Screen / APP
    AccessoriesInverter Power Cable, Parallel Cable, Communication Cable, Grounding Wire
    ColorWhite / Gray / Black
    Design Life20 Years
    Warranty10 Years
    User ManualWith the Battery Packaging
    Certification & Safety StandardUL / FCC / CE / IEC / RoHS / UN38.3 / MSDS
    Inverter
    Regional StandardEUUS
    PV Charge
    Solar Charge TypeMPPT
    Maximum Output Power5kWh
    PV Charging Current Range0~80A
    PV Operating Voltage Range120V~500V
    MPPT Voltage Range120V~450V
    AC Charge
    Maximum Charge Power2100W
    AC Charge Current Range0~60A0~40A
    Rated Input Voltage220V / 230V110V / 120V
    Input Voltage Range90V~280V90V~140V
    AC Output
    Rate Output Power5kW
    Maximum Output Current40A
    Frequency50Hz / 60Hz
    Overload Current40A
    Inverter Output
    Rate Output Power5kW
    Maximum Peak Power10kVa7kVa
    Power Factor1
    Rated Output Voltage (Vac)230V120V
    Frequency50Hz / 60Hz
    Auto Switch Period<15ms
    THD<3%
    Communication InterfaceUSB / RS485 (WiFi / GPRS) Dry node control

    Why use a Lithium Battery?


    High Energy Density: Lithium batteries have a high energy density, which means they can store a significant amount of energy relative to their size and weight. This makes them ideal for portable electronic devices such as smartphones, laptops, and electric vehicles, where space and weight are important considerations.


    Longer Life Cycle: Lithium batteries have a longer life cycle compared to other types of rechargeable batteries. They can be charged and discharged many times before their capacity significantly degrades. This makes them more durable and cost-effective in the long run.


    Low Self-Discharge: Lithium batteries have a low self-discharge rate, which means they retain their charge for a longer period when not in use. This makes them suitable for applications where the battery may sit idle for extended periods, such as emergency backup power or devices that are used infrequently.



    CUSTOM BATTERY SOLUTIONS


    Redway Battery specializes in providing a diverse selection of battery sizes and configurations to cater to a wide range of applications. Whether you need standard battery options or have unique power requirements, our team of experienced engineers is here to assist you throughout the entire process of designing, developing, testing, and manufacturing custom battery solutions tailored to your specific needs. Feel free to reach out to us today to learn more about our comprehensive range of battery solutions and how we can create a customized solution for you.

    5Kwh 10Kwh All In One ESS Solution 15Kwh 20Kwh 25Kwh Lithium Ion Battery For Inverter


    All Redway Products Come with:

    REDWAY PROMISE

    6000 TIMES CYCLES ISO9001,ISO14001, OHSAS18001, EXW, FOB, DAP,DDP
    5 YEARS WARRANTY CE, CB, UL, KC, FCC, BIS, IEC62133. T/T, L/C OPTIONAL
